57mm Round Brushless DC Gear Motor 4000RPM46W 36 Volt 4000RPM
  • name

57mm Round Brushless DC Gear Motor 4000RPM46W 36 Volt 4000RPM

MOQ: 1 set
Price: Negotiation
Standard Packaging: Foam+Hard Carton or Wooden Case+Waterproof film
Delivery Period: 5-10 working days
Payment Method: T/T, PayPal, Western Union
Supply Capacity: 10000pcs/month
Details Information
Product Description
Detail Information
Place of Origin
Changzhou, China
Brand Name
Hontru
Certification
CE ISO RoHS
Model Number
HC57BLF
Document
Product Brochure PDF
Name:
57mm Round Brushless Motor
Number Of Poles:
4
Number Of Phases:
3
Rated Voltage (VDC):
24
Rated Speed (rpm):
3000
Winding Method:
Y
Hall Distribution Angle:
120°
Insulation Level:
B
Insulation Resistance:
100MΩ Min.500VDC
Dielectric Strength:
600VAC,1Min.
Maximum Radial Load:
28N
Maximum Axial Load:
10N
Highlight:

57mm Round Brushless DC Gear Motor

,

Brushless DC Gear Motor 4000RPM

,

36 volt brushless motor

Product Description

57mm Square Brushless Motor



Specification





Item index parameter
Winding method Y
Hall distribution angle 120°
Insulation level B
Insulation resistance 100MΩ Min.500VDC
Dielectric strength 600VAC,1Min.
Maximum radial load 28N
Maximum axial load 10N



Wiring
Function Definition Color Wire Gauge
+5V Red







AWG26 UL1430
Hu White
Hv Blue
Hw Green
GND Black
U White



AWG22 UL1430
V Blue
W Green





Motor model HC57BLY47 HC57BLY52 HC57BLY62 HC57BLY72 HC57BLY92 HC57BLY112
Number of poles 4
Number of phases 3
Rated voltage (VDC) 24
Rated speed (rpm) 3000
Rated torque (N.m) 0.07 0.11 0.18 0.22 0.33 0.45
Rated current (A) 1.5 2 3.5 4 6 8
Rated power (W) 25 41 57 79 110 140
Peak torque (N.m) 0.21 0.33 0.54 0.66 0.99 1.35
Peak current (A) 4.5 6 10.5 12 18 24
Back EMF constant (Vrms/Krpm) 6 6.3 6.4 6.2 6 6.5
Torque constant (N.m/A) 0.058 0.062 0.06 0.059 0.057 0.065
Moment of inertia (g.cm2) 30 45 60 120 180 240
Body length L (mm) 47 52 62 72 92 112
Weight (kg) 0.33 0.45 0.65 0.8 0.95 1.2









  Outline:

    57mm Round Brushless DC Gear Motor 4000RPM46W 36 Volt 4000RPM 0

Tags:

brushless dc gear motor,

brushless gear motor,

brushless planetary gear motor
