Name: 42mm Round Flange Brushless Motor With 40mm Planetary Gearbox
Brand: changzhou hontru motor co.ltd
SKU: HC42BLFS
Availability: InStock

MOQ:	1 set
Price:	Negotiation
Standard Packaging:	Foam+Hard Carton or Wooden Case+Waterproof film
Delivery Period:	5-10 working days
Payment Method:	T/T, PayPal, Western Union
Supply Capacity:	10000pcs/month

Details Information

Product Description

Detail Information

Place of Origin

Changzhou, China

Brand Name

Hontru

Certification

CE ISO RoHS

Model Number

HC42BLFS

Document

Product Brochure PDF

Name:

42mm Round Brushless Motor

Number Of Poles:

Number Of Phases:

Rated Voltage (VDC):

Rated Speed (rpm):

3000

Winding Method:

Hall Distribution Angle:

120°

Insulation Level:

Insulation Resistance:

100MΩ Min.500VDC

Dielectric Strength:

600VAC,1Min.

Maximum Radial Load:

28N

Maximum Axial Load:

10N

Highlight:

42mm Round Flange Brushless Motor

brushless motor gearbox

brushless planetary gear motor

Product Description

42mm Round Brushless Motor

Specification

Item	index parameter
Winding method	Y
Hall distribution angle	120°
Insulation level	B
Insulation resistance	100MΩ Min.500VDC
Dielectric strength	600VAC,1Min.
Maximum radial load	28N
Maximum axial load	10N

Wiring
Function Definition	Color	Wire Gauge
+5V	Red	AWG26 UL1430
Hu	White
Hv	Blue
Hw	Green
GND	Black
U	White	AWG22 UL1430
V	Blue
W	Green

Motor model	HC42BLY40	HC42BLY60	HC42BLY85	HC42BLY95
Number of poles	4
Number of phases	3
Rated voltage (VDC)	24
Rated speed (rpm)	3000
Rated torque (N.m)	0.04	0.07	0.12	0.18
Rated current (A)	0.8	1.5	2.1	3.2
Rated power (W)	12	22	38	56
Peak torque (N.m)	0.12	0.21	0.36	0.54
Peak current (A)	2.4	4.5	6.3	9.6
Back EMF constant (Vrms/Krpm)	6	6	6	6
Torque constant (N.m/A)	0.057	0.057	0.057	0.057
Moment of inertia (g.cm2)	24	33	84	96
Body length L (mm)	40	60	85	95
Weight (kg)	0.3	0.45	0.65	0.8

Outline:

42mm Round Flange Brushless Motor With 40mm Planetary Gearbox 0
