Name: 24V 100W DC Brushless Planetary Gear Motor Brushless Motor Gearbox
Brand: changzhou hontru motor co.ltd
SKU: HC86BLF
Availability: InStock

MOQ:	1 set
Price:	Negotiation
Standard Packaging:	Foam+Hard Carton or Wooden Case+Waterproof film
Delivery Period:	5-10 working days
Payment Method:	T/T, PayPal, Western Union
Supply Capacity:	10000pcs/month

Details Information

Product Description

Detail Information

Place of Origin

Changzhou, China

Brand Name

Hontru

Certification

CE ISO RoHS

Model Number

HC86BLF

Document

Product Brochure PDF

Name:

HC42BLFS Brushless Reducer

Gearbox Housing Material:

Metal

Backlash:

≤1.2°

Radial Clearance:

≤0.05mm

Axial Clearance::

≤0.3mm

Reduction Ratio:

3.7 10、13、19 32、51、71、 100 139、188、264 、369 516

Rated Allowable Torque(N.m):

2 6 12 12

Instantaneous Maximum Torque(N.m):

6 18 36 36

Efficiency(%):

90% 81% 73% 65%

Box LengthL1(mm):

31.8 43.1 54.4 65.7

Level Grade:

1 2 3 4

Highlight:

24V 100W Gear Brushless DC Motor

Planetary Gear Motors

brushless motor gear

Product Description

HC42BLFS Brushless Reducer

1. Gearbox housing material: metal
2. Backlash: ≤1.2°
3. Radial clearance: ≤0.05mm
4. Axial clearance: ≤0.3mm
5. The allowable torque of the gearbox must not be exceeded during use

Gearbox technical parameters:

Reduction ratio	Rated allowable torque(N.m)	Instantaneous maximum torque(N.m)	efficiency(%)	Box lengthL1(mm)	Level grade
3.7	2	6	90%	31.8	1
10,13,19	6	18	81%	43.1	2
32,51,71, 100	12	36	73%	54.4	3
139,188,264 ,369 516	12	36	65%	65.7	4

Motor technical parameters:

Motor model	HC42BLFS40	HC42BLFS60	HC42BLFS80	HC42BLFS100
Number of poles	8	8	8	8
Number of phases	3	3	3	3
Rated voltage (VDC)	24	24	24	24
Rated speed (rpm)	4000	4000	4000	4000
Rated torque (N.m)	0.063	0.125	0.185	0.25
Rated current (A)	2	3.5	5.5	7.5
Rated power (W)	21	41	63	81
Body length L (mm)	40	60	80	100
Weight (kg)	0.3	0.45	0.65	0.8

Outline:

24V 100W DC Brushless Planetary Gear Motor Brushless Motor Gearbox 0
